| Name | KF-RF-I | KF-RF-II | KF-RF-III | KF-RF-V |
| Stainner | ||||
| Throughput | 100 Slides per Hour | 200 Slides per Hour | 300 Slides per Hour | 600 Slides per Hour |
| Rack Slides Capacity | 8 | 30 | 30 | 30 |
| Macroslide Rack Available | No | Yes | Yes | Yes |
| Total Number of Stations | 24 | 27 | 30 | 35 |
| Total Number of Reagent Stations | 16 | 20 | 21-23 (Standard: 21; expandable up to 23) | 23-27 (Standard: 23; expandable up to 27) |
| Volume of Reagent Container(ml) | 160 | 450 | 450 | 750±50, Can Replace with 450 |
| Total Number of Washing Stations | 4 | 4 | 4 | 4 |
| Total Number of Regent Heating Stations | 4 | 4 | 4 | 2-6 (Standard: 2; expandable up to 6) |
| Drying Oven Stations | 2 | 1 | 1 | 2 |
| Stations in Input and Output Drawer | 1 | 1 | 3 | 6 |
| Loading Capacity | 8 slides | 30 slides | 30 slides * 2 | 30 slides * 10 |
| In Staining Rack Capacity | 10 | 10 | 12 | 22 |
| Reagent Heating Station Temperature Range | 0℃~60℃ | 0℃~60℃ | 0℃~60℃ | 0℃~60℃ |
| Reagent Heating Temperature Control Accuracy | ±1°C | ±1°C | ±1°C | ±1°C |
| Maxium Program Storage Number | 24 | 24 | 24 | 24 |
| Program Steps | Up to 54 | Up to 54 | Up to 54 | Up to 54 |
| Certifications | CE-IVDR | CE-IVDR | CE-IVDR | CE-IVDR |
| Monitor Size | 7 inch | 11.6 inch | 11.6 inch | 12 inch |
| Voice Reminder | Yes | Yes | Yes | Yes |
| Coverslipper | ||||
| Integration Type | Inside | Inside | Inside | Inside |
| Cover glass sizes(mm) | 24*50 | 24*50 | 24*50 | 24*50 |
| Throughput | 200 Slides /Hour | 300 Slides /Hour | 400 Slides /Hour | 600 slides / hour |
| Coverslip Storage Capacity | 200 | 200 | 600 | 800 |
| Unloading Capacity | 8 slides * 2 | 30 slides * 3 | 30 slides * 4 | slides * 12 |
| Defective Coverslip Detection | Automatically identifies and rejects damaged or flawed coverslips | Automatically identifies and rejects damaged or flawed coverslips | Automatically identifies and rejects damaged or flawed coverslips | Automatically identifies and rejects damaged or flawed coverslips |
| Empty Coverslip Detection | Monitors real-time coverslip availability | Monitors real-time coverslip availability | Monitors real-time coverslip availability | Monitors real-time coverslip availability |
| Low Inventory Pre-Alert | Triggers a warning before coverslips are fully depleted to ensure uninterrupted operation. | Triggers a warning before coverslips are fully depleted to ensure uninterrupted operation. | Triggers a warning before coverslips are fully depleted to ensure uninterrupted operation. | Triggers a warning before coverslips are fully depleted to ensure uninterrupted operation. |
| Output rack capacity | 16 | 90 | 120 | 360 |
| Monitor Size | / | / | 8.8 inch | 8.8 inch |
| DIMENSIONS & WEIGHT & POWER | ||||
| Dimension (W x L x H) |
920mm x 530mm x 550mm | 1270mm x 590mm x 760mm | 1528mm x 625mm x 705mm | 1903mm x 715mm x 695mm |
| Weight | 100kg | 130kg | 165kg | 205kg |
| Air Freight Crate Dimension (W x L x H) |
1040mm*710mm*810mm | 1390mm*710mm*940mm | 1710mm*720mm*965mm | 2090mm*820mm*970mm |
| Air Freight Crate Weight | 140kg | 180kg | 235kg | 285kg |
| Ocean Freight Wooden Crate Dimensions (W x L x H) |
1030mm*690mm*720mm | 1400mm*730mm*850mm | 1730mm*740mm*875mm | 2110mm*840mm*880mm |
| Ocean Freight Wooden Crate Weight | 120kg | 160kg | 210kg | 250kg |
| Power Supply Voltage Range | 100–240V AC, 50/60Hz | |||
| Power Socket Type | Type A、Type C、 Type D、Type E/F、Type G、Type I、Type J、Type L、Type M | |||
| Rated Power | 150VA | 200VA | 200VA | 200VA |
