Beyond digital pathology scanner

We design and manufacture scanners to meet the needs of diverse application scenarios.

From 5 to 400 slides

our five throughput models are built for any workload scenario. Engineered for precise, automated scanning of all slide types, they seamlessly adapt their mode to the task. Coupled with a complete software suite, they transform scanned data into actionable insights—streamlining storage, management, diagnostics, research, and analysis.

True-to-Life Color, Built on Precision.

Our scanners deliver unmatched color fidelity through Independent Three-Channel Processing and the proprietary K-SCP (Specialized Color Processing) engine. This integrated system systematically enhances color, saturation, white balance, and contrast for exceptional image accuracy.

With built-in ICC profile calibration, colors remain consistent and reliable across all displays. From precise capture to faithful presentation, every digital slide is rendered perfectly trustworthy.

Unrivaled Optics, Unmatched Clarity.

We achieve a dramatic leap in optical resolution through holistic optimization of the entire imaging chain—from the light source and objectives to the camera and optical pathway. This premium configuration reveals exquisite cellular details, delivering images with razor-sharp nuclear edges and crisply defined internal architecture.

The KF-PRO Series at a glance

0 s
Per slide at 20× (15×15 mm)
0 nm
Stage positioning accuracy
0 NA
Apochromatic 20× objective
0
Gbps · dual Camera Link card
0
Slides per load (5 to 400)
KF-PRO-005 digital pathology slide scanner - 5 slide capacity

KF-PRO-005

5-slide capacity

KF-PRO-020 digital pathology slide scanner - 20 slide capacity

KF-PRO-020

20-slide capacity

KF-PRO-040 digital pathology slide scanner - 40 slide capacity

KF-PRO-040

40-slide capacity

KF-PRO-120 digital pathology slide scanner - 120 slide capacity

KF-PRO-120

120-slide capacity

KF-PRO-400 digital pathology slide scanner - 400 slide capacity

KF-PRO-400

400-slide capacity

Core technology

Precision engineering, from optics to motion

Every KF-PRO scanner is a tightly integrated opto-mechatronic instrument, built to capture vast amounts of microscopic data at speed without compromising image quality.

Maglev Linear-Motor Drive

The same magnetic-suspension linear motor used in semiconductor lithography, paired with optical-grating closed-loop position feedback. High thrust, non-contact and frictionless for silent, ultra-stable scanning with positioning accuracy down to the nanometre scale.

Tri-Linear Line-Scan Camera

Three independent sensors capture R, G and B separately with no cross-channel interference, reducing chromatic aberration for true-to-life colour. 4K pixels at a 7.5µm pitch and up to 10 Gbps deliver richer detail with seamless, seam-free stitching.

Apochromatic X-Line Optics

Evident (Olympus) X-Line UPLXAPO 20× NA 0.8 apochromatic objective — flat field, corrected chromatic aberration — reveals crisp nuclear edges and clearly defined internal structure. Optional 40× NA 0.95 for the highest magnification needs.

High-Precision Autofocus

Automatic focus across a 0.25µm depth of field keeps every field sharp, while Z-stack scanning (up to 10 layers) with multi-layer image fusion captures thick and cytology specimens in full three-dimensional clarity.

Grows with your lab

Field-upgradeable fluorescence

Every model except the KF-PRO-040 can be upgraded to fluorescence scanning on the existing instrument — no replacement required. Add an sCMOS camera and a Lumencor-class light engine to unlock 3 to 10 configurable channels with KF-DAPI, GREEN, ORANGE, RED, CY5 and CY7 filter sets.

KF-PRO-005

Fluorescence-ready

KF-PRO-020

Fluorescence-ready

KF-PRO-040

Brightfield only

KF-PRO-120

Fluorescence-ready

KF-PRO-400

Fluorescence-ready

KF-PRO-040 is a brightfield-only configuration.

Where it is used

One platform, every pathology workflow

From single-slide desktop use to fully automated 400-slide laboratories, the KF-PRO Series adapts to the way each institution works.

Clinical Diagnosis

Full-slide digitisation and AI-assisted primary diagnosis for high-throughput pathology departments.

Telepathology

Share whole-slide images instantly for remote consultation, second opinions and multi-site review.

Scientific Research

Quantitative analysis, biomarker research and reproducible imaging for disease and drug studies.

AI-Assisted Diagnosis

Consistent, high-fidelity images form the reliable data foundation that pathology AI models depend on.

Education & Training

Build searchable digital slide libraries for teaching, proficiency testing and archival.
IMAGING & CAPACITY
Name KF-PRO-005 KF-PRO-020 KF-PRO-040 KF-PRO-120 KF-PRO-400
Brightfield
Magnification 20x & 40x
Speed 15 sec/slide
Resolution 0.25 um/pixel at 20x, 0.125 um / pixel at 40x
Scan Method Line Scan
Output Format .KFB, .SVS, .DCM, .TIFF
Fluorescence
Upgrade to Support Fluorescence Yes Yes No Yes Yes
Speed ≤6 min / slide, 10mm * 10mm, 3 filters
≤12 min / slide, 10mm * 10mm, 6 filters
Resolution 0.25 um/pixel at 20x
0.125 um/pixel at 40x
Scan Method Area Scan
Camera Sensor Type sCMOS
Output Format .KFBF, .QPTIFF
Common Parameters
Scanning Region 25mm * 50mm
50mm * 50mm
100mm * 50mm		 25mm * 50mm
50mm * 50mm		 25mm * 50mm 25mm * 50mm 25mm * 50mm
Field of View (FOV) 1mm
Z-Stack Scanning ≤10 layers
Multi Layer Image Fusion Support
Objective Lens Evident X-Line UPLXAPO 20X, UPLXAPO 40X
Objective Lens Evident X-Line UPLXAPO 20X, UPLXAPO 40X
Slide Capacity 5 20 40 120 400
Slide Holder Type Tray Tray Rack Rack Rack
Slide Holder Capacity 5 2 40 40 40
Slide Holder Number 1 10 1 2 10
Label Identification Support
DIMENSIONS & WEIGHT & POWER
Scanner Dimensions
(W x L x H)		 470mm x 510mm x 570mm 490mm x 545mm x 565mm 490mm x 500mm x 565mm 585mm x 515mm x 675mm 525mm x 650mm x 655mm
Scanner Weight 53kg 55kg 54kg 71kg 79kg
Air Freight Crate Dimensions (W x L x H) 700mm x 730mm x 920mm 700mm x 730mm x 920mm 700mm x 730mm x 920mm 830mm x 880mm x 920mm 830mm x 880mm x 920mm
Air Freight Crate Weight(Including Scanner) 81kg 83kg 82kg 106kg 114kg
Power Supply Voltage Range 100–240V AC, 50/60Hz
Power Socket Type Type A、Type C、 Type D、Type E/F、Type G、Type I、Type J、Type L、Type M
Rated Power 150VA 200VA 200VA 200VA 200VA
IT & COMPUTER
PC Model Dell QBT1250
PC Parameter CPU: Ultra 5 245
Memory: 16G
Harddisk: 1T SSD		 CPU: Ultra 5 245
Memory: 16G
Harddisk: 1T SSD		 CPU: Ultra 5 245
Memory: 16G
Harddisk: 1T SSD		 CPU: Ultra 7 265
Memory: 16G
Harddisk: 1T SSD		 CPU: Ultra 7 265
Memory: 16G
Harddisk: 1T SSD
Memory upgrade 64 GB minimum recommended when multi-layer (Z-stack) scanning is required
Monitor 24 Inch
Network Adopter 1Gb RJ45 * 1
Operation System Windows 11 Professional
Slides
General The tissue/smear must be mounted with a coverslip, glass or tape.
Standard 1-inch x 3-inch (2.54 cm x 7.62 cm) slides. Compatiable with ISO 8037/1.
Minimum Slide Size
(W x L)		 25mm * 50mm 25mm * 75mm 25 mm x 75 mm 25 mm x 75 mm 25 mm x 75 mm
Maximum Slide Size
(W x L)		 104mm * 76mm 52mm * 76mm 26 mm x 76 mm 26 mm x 76 mm 26 mm x 76 mm
Thickness 0.9 mm ~ 1.1 mm, excluding coverslip
Special Requirement The coverslip and attached label must remain fully within the microscope slide perimeter, secured with complete adhesive contact. All surfaces shall lie flat without edge separation. The slide exterior must maintain dryness with no fluid leakage from the specimen zone.
Maximum Tissue/Smear Thickness Optimized for tissue thickness of 3-5 μm (including mounting media)
Coverslips Accepted The coverslip/label assembly (0.17 mm nominal thickness, standard borosilicate glass or cellulose tri-acetate film) must maintain full edge registration with the microscope slide substrate through continuous adhesive bonding. All interfacial surfaces shall exhibit co-planar adhesion integrity with zero delamination, while the external slide surfaces remain contamination-free from residual fluids or specimen migration.
Label Area (W x L) 25 mm x 25 mm
Label Special Requirement Adhesive labels must maintain non-protrusive margins within slide boundaries and demonstrate full-surface lamination to the coverslip interface plane (upper slide surface). Prohibited from substrate attachment on the specimen observation surface (lower slide plane), all labeling components shall exhibit edge-to-edge planar adhesion without delamination defects.
Barcodes Supported 1D and 2D Barcode, QRCode, DataMatrix Code

Data you can use anywhere

Supported image & file formats

KF-PRO scanners output open, widely adopted formats for both brightfield and fluorescence, so your digital slides integrate smoothly with viewers, storage and analysis tools.

KFB & KFBF

KFBIO native formats — KFB for brightfield and KFBF for fluorescence — optimised for fast pyramidal viewing in the KFBIO software suite.

SVS

Aperio-compatible tiled pyramid format, widely supported across third-party viewers, image-analysis tools and AI pipelines.

TIFF / QPTIFF

Universal tiled pyramidal TIFF for brightfield, and QPTIFF for multi-channel fluorescence with preserved channel metadata.

DICOM (WG26)

Standards-based DICOM whole-slide imaging for seamless integration with PACS, LIS and hospital information systems.

Open interoperability

Export the same scan to multiple formats so data flows freely between clinical, research and archival systems without vendor lock-in.

AI & analysis ready

Formats chosen for direct compatibility with common deep-learning frameworks and quantitative pathology software.

Fully compatible with the WG26 digital pathology DICOM file format

This comprehensive compatibility ensures that KFBIO scanners can seamlessly generate, process, and exchange DICOM-compliant digital pathology images, enabling smooth integration with hospital information systems, pathology databases, and other medical devices for enhanced interoperability in clinical and research workflows.The DICOM digital pathology format is a specialized extension of the DICOM (Digital Imaging and Communications in Medicine) standard, designed specifically for pathology imaging. It standardizes the storage, transmission, and management of whole slide images (WSI) and associated data, such as annotations, metadata, and clinical information. By providing a consistent framework, this format facilitates reliable data exchange across different platforms and vendors, supporting key applications in telepathology, artificial intelligence analysis, and long-term archival. It promotes efficiency, accuracy, and collaboration in modern digital pathology practices.

For official information on the DICOM standard and the WG26 digital pathology specifications, please visit the DICOM website.

Good to know

Frequently asked questions

The series spans five throughput levels — KF-PRO-005, -020, -040, -120 and -400 — with slide capacities of 5, 20, 40, 120 and 400 slides respectively. This lets you match the instrument to anything from a single-slide desktop workflow to a fully automated high-volume laboratory.

In brightfield at 20× the KF-PRO Series scans a 15×15 mm region in about 15 seconds per slide, reaching up to 72 slides per hour at 20×. Speed depends on the scan area, focus points and magnification selected.

Scanning resolution is 0.25 µm/pixel at 20× and 0.125 µm/pixel at 40×, using an Evident (Olympus) X-Line UPLXAPO 20× apochromatic objective at NA 0.8. An optional 40× NA 0.95 objective is available for the highest-magnification needs.

Every model except the brightfield-only KF-PRO-040 can be upgraded to fluorescence on the existing instrument. The fluorescence module supports 3 to 10 configurable channels (KF-DAPI, GREEN, ORANGE, RED, CY5 and CY7 filter sets) using an sCMOS camera and a solid-state light engine.

Brightfield scans are saved as KFB, SVS, TIFF or DICOM, and fluorescence scans as KFBF or QPTIFF. The same scan can be exported to multiple formats so data integrates with viewers, storage, PACS/LIS and AI-analysis tools without vendor lock-in.

Yes. The scanners are fully compatible with the WG26 digital-pathology DICOM standard for whole-slide imaging, enabling reliable exchange with hospital information systems, pathology databases and other medical devices.

Yes. Z-stack scanning captures up to 10 layers with multi-layer image fusion, so thick tissue and cytology preparations are rendered with full three-dimensional clarity across a 1 mm field of view.

Yes. Consistent, high-fidelity output in open formats (SVS, TIFF, DICOM) makes KF-PRO scans a reliable data foundation for AI-assisted diagnosis and quantitative pathology, and they are already trusted by more than 1,500 medical institutions.

Ready for what comes next

A solid foundation for pathology AI

Open, standards-based output (KFB, SVS, TIFF and DICOM WG26) and consistent, high-fidelity imaging make KF-PRO scanners the dependable data source that AI-assisted diagnosis and research are built on — already trusted by more than 1,500 medical institutions.
